Specifications
Print

Print Method

Dye Sublimation Direct Print

Resolution

300 dpi

Input

RGB 256 level

Output

CMY 256 level

Printing Area

Edge-to-Edge
Speed

Single Side YMCKO

128 cards/hr

Double-Sided YMCKO

66 cards/hr
Capacity

Feeder Capacity

100 cards (if card thickness is 0.76mm)

Card Exit Capacity

100 cards (if card thickness is 0.76mm)
Card

Card thickness

20 mil – 50 mil (.25mm-1.27mm) 10 mil Special Order

Card Size

CR80 (85.6cm x 54cm)

Card material

PVC, PVC Composite
Display

LCD Display Panel (with Backlight), LED, Operation Button
Size

Dimensions

16.57(H) x 10.66(W) x 13.03(D) inches (421(H) x 271(W) x 331(D) mm)

Weight

Less than 26.61 lbs. (13kg)
Power

Power Source

90-125VAC 220-240VAC 50/60Hz

Power Consumption

Less than 120 W
Operating Temperature

15 to 35°C – 20 to 80% humidity
Drivers

I/F

USB, Ethernet

Drivers

XP, Vista, Win 8 (32/64 bits), Win8., Win 10
Ribbon

Ribbon Capacity

250 images / roll (YMCKO ribbon)

Ink Ribbon

YMCKO, K
Agency Listing

UL/CSA/CE/FCC
Life

MTBF

100,000 prints

Warranty

3 years2
Memory Size

32MB
Security Features

Click here to learn more about our layers of security
  • Contactless Encoder (Mifare, Legic, HD Prox, iCLASS)
Drivers
NiSCA PR-C151 Windows Driver v1.01 Build 195 (Updated verification to security certificate embedded in INF file processing for XP OS) .zip / 15.76 MB
Firmware
PR-C151 Firmware v1.3 .zip / 944.58 KB
Manuals & Programmer References
Team NiSCA General Terms and Conditions of Sale .pdf / 180.40 KB
PR-C151 / PR-C201 Print Driver Installation Guide .pdf / 1.49 MB
PR-C151 Operation Guide .pdf / 1.91 MB
How to check the firmware version .pdf / 286.35 KB
How to update the firmware .pdf / 173.86 KB
Engineering Change Notice .pdf / 396.56 KB
Brochure
PR-C151 Brochure .pdf / 1.83 MB

1. Due to policy of continuous development, we reserve the right to alter details of specification and equipment without notice.
2. Please contact Team NiSCA for more information.
