PR-C201
Full Bleed Retransfer PrinterNiSCA’s retransfer printing technology allows you to print FULL COLOR, FULL BLEED IMAGES in brilliant true color. The retransfer process uses dye sublimation to print a high-resolution image in reverse directly onto the film base. The printer then thermally transfers the image and film onto the card surface through heat and pressure, thermally bonding it to the card surface. The PR-C201 offers a high speed, 600 dpi, 24-bit color and prints at the astounding speed of over 1451 cards/hour! The PR-C201 comes available with an optional encoder, contact encoder and/or contactless encoder.
| DPI | 600 |
|---|---|
| 24-bit continuous tone printing | Yes |
| Dual-sided printing | Yes |
| Inline encoding options | Contactless/Smart/IC Contact2 |
| Separate image and function memory | Yes |
| Extended image memory, MB | Yes, 64 |
| Printing speed YMCK, cards/hour | 1452 |
| Printing speed resin, cards/hour | TBA |
| Printing speed single-sided lamination, cards/hour | 145 |
| Printing speed dual-sided lamination, cards/hour | TBA |
| Ultraviolet printing capability | Yes |
| Micro printing capability | Yes |
| Card size | CR79 & CR80 |
| Card thickness, mil | 25 to 50 |
| Card input/output hopper | 250/250 |
| Windows 2000/XP/VISTA/7/8/10 32 or 64 bit | Yes |
| Security over-laminate add-on module | Yes |
| Warranty | 3 years3 |
| Security Features | Click here to learn more about our layers of security |
|
| Drivers |
|
||||||||
|---|---|---|---|---|---|---|---|---|---|
| Firmware |
|
||||||||
| Manuals & Programmer References |
|
1. YMCKO
2. Due to policy of continuous development, we reserve the right to alter details of specification and equipment without notice.
3. Please contact Team NiSCA for more information.
